Torpedo level with magnetic does not work Troubleshooting and solutions

I. Analysis of possible causes

1. Sampling valve problem

The sampling valve is a key component that connects the measured liquid and the main pipe of the torpedo level with magnetic. Its state directly affects the accuracy of the liquid level measurement. If the sampling valve is not opened normally or the opening is too small, the liquid flow will be blocked and cannot flow smoothly into the main pipe, which will affect the normal rise and fall of the float. In this case, even if the liquid level changes, the torpedo level with magnetic cannot accurately reflect it, causing misreading or no action at all.

2. Float blocking

The float is the core component of the torpedo level with magnetic. It rises and falls with the liquid level and drives the flap to flip through the magnetic force, thereby indicating the liquid level height. However, the float may encounter various blocking situations during operation:

Foreign matter blocking: The measured medium may contain impurities, sediments, etc. These substances are easy to accumulate around the float, or even directly jam the float, making it unable to rise and fall freely.

Surface adsorption: After working for a long time, a layer of impurities may be adsorbed on the surface of the float. These impurities increase the friction between the float and the pipe wall, causing the float to move poorly or even completely blocked.
Design or installation problems: The size and shape of the float are not well matched with the inner wall of the main pipe, or the medium characteristics are not fully considered during installation, which may also cause the float to be blocked.
2. Solution
1. Check and adjust the sampling valve
Regular inspection: Check the sampling valve regularly to ensure that it is in a fully open or appropriate opening state to avoid poor liquid flow due to the valve not being open or the opening being too small.
Cleaning and maintenance: Regularly clean the impurities around the sampling valve and keep the inside of the valve clean to ensure that the liquid can pass smoothly.
2. Solve the problem of float blocking
Cleaning foreign matter: For the float that does not move due to foreign matter blocking, the relevant valve should be closed first, some liquid should be drained, and then the impurities around the float and the float should be manually cleaned.
Surface cleaning: Clean the surface of the float regularly to remove adsorbed impurities, reduce friction, and keep the float flexible.
Optimize design: For jamming caused by design or installation problems, consider adjusting the size and shape of the float, or optimizing the finish of the inner wall of the main pipe to reduce the possibility of friction and jamming.
Add protective measures: In situations where the medium contains a large amount of impurities or sediment, consider adding a filter or sedimentation tank in front of the torpedo level with magnetic to reduce the chance of impurities entering the main pipe and float.
